Wheel: | Electrostatic Painting | Min Bend Radius: | 295mm |
---|---|---|---|
Breaking Tension: | 100Kg | Glassfiber Density: | 55g/m |
Size: | 9MM* 150M | ||
High Light: | 9mmx150m Fiberglass Duct Rodder,OEM Fiberglass Duct Rodder,150m conduit rodding equipment |
Glass fiber rod diameter | φ 8.0mm |
Length | 30-100m |
Working temperature | -40+80 |
Min Bend Radius | 295mm |
Breaking tension | 100kg |
Glassfiber density | 55g/m |
Material | imported engineering plastic ABS |
Product NO Length Weight Frame diameter length width height
Mini duct rod 4.5mm 500mm 500mm 170mm 630mm
YT4530 30M 4.5kg
YT4540 40M 4.8kg
YT4550 50M 5.0kg
YT4560 60M 5.2kg
YT4570 70M 5.4kg
YT4580 80M 5.6kg
Mini duct rod 6.0mm 600mm 600mm 200mm 720mm
YT6030 30M 6.0kg
YT6050 50M 8.0kg
YT6060 60M 9.0kg
YT6080 80M 10.0kg
YT60100 100M 11.0kg
YT60120 120M 12.0kg
YT30150 150M 13.0kg
Duct rod 10mm 1000mm 1000mm 450mm 1200mm
YT10100 100M 38kg
YT10120 120M 42kg
YT10150 150M 45kg
YT10200 200M 50kg
YT10250 250M 54kg
Duct rod 11mm 1000mm 1000mm 450mm 1200mm
YT11100 100M 42kg
YT11120 120M 45kg
YT11150 150M 50kg
YT11200 200M 56kg
YT11250 250M 62kg
YT11300 300M 68kg
Duct rod 12mm 1000mm 1000mm 450mm 1200mm
YT12100 100M 43kg
YT12120 120M 46kg
YT12150 150M 51kg
YT12200 200M 58kg
YT12250 250M 64kg
YT12300 300M 70kg
Duct rod 13mm 1200mm 1200mm 450mm 1480mm
YT13100 100M 52kg
YT13120 120M 58kg
YT13150 150M 65kg
YT13200 200M 75kg
YT13250 250M 90kg
YT13300 300M 105kg
Duct rod 14mm 1200mm 1200mm 450mm 1480mm
YT14150 150M 72kg
YT14200 200M 85kg
YT14250 250M 100kg
YT14300 300M 115kg
