| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HC , OEM |
| Certification: | CE , SGS , ISO2018 |
| Model Number: | AXS Series |
| Minimum Order Quantity: | 100 |
| Price: | Negotiable |
| Packaging Details: | Cartons , Wooden Case , Pallets |
| Delivery Time: | 7 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 Sets Per day |
| Material: | Galvanized Steel Or Aluminium Alloy | Link Fitting: | York Plate , TC-07 |
|---|---|---|---|
| Clamp: | AGS Clamp | Outter Rods: | 1800mm-2400mm |
| Length: | 1100MM-3000MM | The Grip Strength: | 100kn |
| High Light: | ADSS ags suspension clamp,ags suspension clamp 100KN,ADSS double suspension clamp |
||
Double ADSS Fiber Cable AGS Suspension Set
1. The Max. unilateral angle of double suspension will be 30º－36º.
2. All the above scheme are Universal Scheme, if use other link fittings, please illuminate in particular.
3. The above items not include all of our products, if you have any requirement, please consult with our technical Department.
Specification (The grip strength of the clamp is bigger than 20% of the rated tensile strength)
| Model | Available Dia. of Cable | Length of Outer Rods |
Length of Structural Reinforcing Rods
|
Weight(kg) | Universal Scheme | ||
| Yoke Plate | AGS Clamp | Link Fittings | |||||
| AXS 0960 | 9.0-9.6 | 1800 | 2200 | 2.36 | L-1040 |
Referrence Table 16.3
|
U-7 |
| AXS 1010 | 9.7-10.1 | 1800 | 2200 | 2.45 | L-1040 | ||
| AXS 1060 | 10.2-10.6 | 1800 | 2200 | 2.61 | L-1040 | ||
| AXS 1110 | 10.7-11.1 | 1800 | 2200 | 2.61 | L-1040 | ||
| AXS 1160 | 11.2-11.6 | 1800 | 2200 | 2.7 | L-1040 | ||
| AXS 1170 | 11.7-11.7 | 1800 | 2200 | 2.7 | L-1040 | ||
| AXS 1200 | 11.8-12.0 | 1900 | 2400 | 2.88 | L-1245 | ||
| AXS 1270 | 12.1-12.7 | 1900 | 2400 | 2.88 | L-1245 | ||
| AXS 1290 | 12.8-12.9 | 1900 | 2400 | 3.15 | L-1245 | ||
| AXS 1360 | 13.0-13.6 | 1900 | 2400 | 3.15 | L-1245 | ||
| AXS 1410 | 13.7-14.1 | 2100 | 2700 | 3.5 | L-1245 | ||
| AXS 1430 | 14.2-14.3 | 2100 | 2700 | 3.81 | L-1245 | ||
| AXS 1450 | 14.4-14.5 | 2100 | 2700 | 3.81 | L-1245 | ||
| AXS 1510 | 14.6-15.1 | 2100 | 2700 | 3.81 | L-1245 | ||
| AXS 1580 | 15.2-15.8 | 2100 | 2700 | 3.81 | L-1245 | ||
| AXS 1600 | 15.9-16.0 | 2100 | 2700 | 3.92 | L-1245 | ||
| AXS 1690 | 16.1-16.9 | 2400 | 3000 | 4.43 | HPL-550 | ||
| AXS 1730 | 17.0-17.3 | 2400 | 3000 | 4.78 | HPL-550 | ||
